Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12460272) - 2019 - crc - 5/8/18

VEHICLE CARE

267

If equipped with the Stop/Start
system, the engine will not engage
Auto Stop after the battery is
disconnected. After reconnecting the
battery, the vehicle must sit
untouched for four hours. See

Auto

Engine Stop/Start

in

Starting the

Engine

0

187

.

Vehicle Storage

{

Warning

Batteries have acid that can burn
you and gas that can explode. You
can be badly hurt if you are not
careful. See

Jump Starting - North

America

0

312

for tips on working

around a battery without
getting hurt.

Infrequent Usage: Remove the black,
negative (

) cable from the battery to

keep the battery from running down.

Extended Storage: Remove the black,
negative (

) cable from the battery or

use a battery trickle charger.

All-Wheel Drive

If the vehicle is equipped with
All-Wheel-Drive (AWD), this is an
additional system that needs
lubrication.

Transfer Case

When to Check Lubricant

It is not necessary to regularly check
the transfer case fluid unless a leak is
suspected or an unusual noise is
heard. A fluid loss could indicate a
problem. Have it inspected and
repaired.

How to Check Lubricant

1. Fill Plug
2. Drain Plug
