Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

15567102) - 2022 - CRC - 8/16/21

INSTRUMENTS AND CONTROLS

111

Wireless Charging

If equipped and enabled, the vehicle
has wireless charging in the center
console in front of the storage bin.
The system operates at 145 kHz and
wirelessly charges one Qi compatible
smartphone. The power output of the
system is capable of charging at a rate
up to 3 amp (15 W), as requested by
the compatible smartphone. See

Radio

Frequency Statement

0

476

.

{

Warning

Wireless charging may affect the
operation of an implanted
pacemaker or other medical devices.
If you have one, it is recommended
to consult with your doctor before
using the wireless charging system.

The vehicle must be on, in ACC/
ACCESSORY, or Retained Accessory
Power (RAP) must be active. The
wireless charging feature may not
correctly indicate charging when the
vehicle is in RAP, during a Bluetooth
phone call, or when phone projection

(e.g. Apple CarPlay / Android Auto) is
active. See

Retained Accessory Power

(RAP)

0

249

.

The operating temperature is

40 °C

(

40 °F) to 85 °C (185 °F) for the

charging system and 0 °C (32 °F) to
35 °C (95 °F) for the phone. A charging
stopped alert may be displayed on the
infotainment screen, if the wireless
charger or smartphone are outside of
normal operating temperature.
Charging will automatically resume
when a normal operating temperature
is reached.

{

Warning

Remove all objects from the charger
before charging your compatible
smartphone. Objects, such as coins,
keys, rings, paper clips, or cards,
between the smartphone and
charger may become very hot.

On the rare occasion that the
charging system does not detect an
object, and the object gets wedged
between the smartphone and
charger, remove the smartphone

(Continued)

Warning (Continued)

and allow the object to cool before
removing it from the charger, to
prevent burns.

To charge a compatible smartphone:

1. Confirm the smartphone is capable

of wireless charging.

2. Remove all objects from the

charging pocket. The system may
not charge if there are any objects
between the smartphone and
charger.

3. Place the smartphone face up

against the rear of the charger.
