Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

15567102) - 2022 - CRC - 8/16/21

INSTRUMENTS AND CONTROLS

119

Voltmeter Gauge

When the ignition is on, the voltmeter
gauge indicates the battery voltage.

This gauge displays on the
infotainment display. If show in
cluster is selected a digital value is
shown on the instrument cluster in
zone 2.

When the engine is running, this
gauge shows the condition of the
charging system. The gauge can
transition from a higher to lower or a
lower to higher reading. This is
normal. If the vehicle is operating
outside the normal operating range,
the charging system light comes on.

See

Charging System Light

0

122

. The

voltmeter gauge may also read lower
when in fuel economy mode. This is
normal.

Readings outside the normal operating
range can also occur when a large
number of electrical accessories are
operating in the vehicle and the
engine is left idling for an extended
period. This condition is normal since
the charging system is not able to
provide full power at engine idle. As
engine speeds are increased, this
condition should correct itself as
higher engine speeds allow the
charging system to create maximum
power.

The vehicle can only be driven for a
short time with the readings outside
the normal operating range. If the
vehicle must be driven, turn off all
accessories, such as the radio and air
conditioner.

Readings outside the normal operating
range indicate a possible problem in
the electrical system. Have the vehicle
serviced as soon as possible.

Seat Belt Reminders

Driver Seat Belt Reminder Light

There is a driver seat belt reminder
light on the center stack, below the
infotainment screen.

When the vehicle is started, this light
flashes and a chime may come on to
remind the driver to fasten their
seat belt.

Then the light stays on solid until the
belt is buckled. This cycle may
continue several times if the driver
remains or becomes unbuckled while
the vehicle is moving.

If the driver seat belt is buckled,
neither the light nor the chime
comes on.
