Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

15567102) - 2022 - CRC - 8/16/21

LIGHTING

155

If after signaling a turn or a lane
change the arrows flash rapidly or do
not come on, a signal bulb could be
burned out.

Replace any burned out bulbs. If a
bulb is not burned out, check the fuse.
See

Fuses and Circuit Breakers

0

391

.

Turn Signal On Chime

If the turn signal is left on for more
than 1.2 km (0.75 mi), a chime sounds
at each flash of the turn signal. The
message TURN SIGNAL ON will also
appear in the Driver Information
Center (DIC). To turn the chime and
message off, move the turn signal
lever to the off position.

Cornering Lamps

If equipped with cornering lamps, they
automatically come on when all of the
following occur:

.

The low-beam headlamps are on.

.

The turn signals are activated or the
steering wheel is at a turning angle.

.

The vehicle speed is below 40 km/h
(25 mph) .

Interior Lighting

Instrument Panel
Illumination Control

This feature adjusts the brightness of
all illuminated controls.

The display brightness automatically
adjusts based on outdoor lighting.

D

:

Move the thumbwheel up or

down to brighten or dim the lights.

The thumbwheel is functional at
night, or when the headlamps or
parking lamps are on.

Interior Lamps

Interior Ambient Lighting

If equipped, this feature allows the
color of the interior lighting in the
vehicle to be chosen.

To access, press

{

on the

infotainment controls, then touch
AMBIENT LIGHTING to display the
settings screen.

Touch to select from the following:

OFF :

Turns the feature off.

ON :

Turns the feature on. Ambient

lighting provides the ability to
customize the color and intensity of
the interior accent lighting. Chose the
color on the display screen to make
change to interior lighting color.

DEMO MODE :

When the shift lever

is in P (Park), touch to turn the
feature on in colors chosen by the
vehicle. When the shift lever is not in
P (Park) , the interior color will default
to the last active color selected.

LINK TO DRIVE MODE :

The light

color is matched to the color being
used for the drive mode.
