Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

15567102) - 2022 - CRC - 8/16/21

246

DRIVING AND OPERATING

A sound may be heard as the lock
actuates or releases. The steering
column lock may not release with the
wheels turned off center. If this
happens, the vehicle may not start.
Move the steering wheel from left to
right while attempting to start the
vehicle. If this does not work, the
vehicle needs service.

If the vehicle must be shut off in an
emergency:

1. Brake using a firm and steady

pressure. Do not pump the brakes
repeatedly. This may deplete power
assist, requiring increased brake
pedal force.

2. Shift the vehicle to N (Neutral).

This can be done while the vehicle
is moving. After shifting to
N (Neutral), firmly apply the brakes
and steer the vehicle to a safe
location.

3. Come to a complete stop.
4. Hold the brake pedal down and

shift to P (Park). The shift lever
must be in P (Park) to turn the
ignition off.

5. Continue to hold the brake

pedal down.

6. Set the parking brake. See

Electric

Parking Brake

0

261

.

7. Press ENGINE START/STOP once

to turn the ignition off.

8. Release the brake pedal.

If the vehicle cannot be pulled over,
and must be shut off while driving,
press and hold ENGINE START/STOP
for longer than two seconds, or press
twice in five seconds.

ACC/ACCESSORY (Amber Indicator
Light) :

This mode allows some

electrical accessories to be used when
the engine is off.

With the ignition off, pressing the
button one time without the brake
pedal applied will place the ignition
system in ACC/ACCESSORY.

The ignition will switch from ACC/
ACCESSORY to off after five minutes
to prevent battery rundown.

ON/RUN/START (Green Indicator
Light) :

This mode is for driving and

starting. With the ignition off, and the
brake pedal applied, pressing the

button once will turn the ignition on.
Once engine cranking begins, release
the button. Engine cranking will
continue until the engine starts. See

Starting the Engine

0

246

.

Service Mode

This power mode is available for
service and diagnostics, and to verify
the proper operation of the
malfunction indicator lamp as may be
required for emission inspection
purposes. With the vehicle off, and the
brake pedal not applied, pressing and
holding the button for more than
five seconds will place the vehicle in
Service Mode. The instruments and
audio systems will operate as they do
when the ignition is on, but the
vehicle will not be able to be driven.
The engine will not start in Service
Mode. Press the button again to turn
the ignition off.

Starting the Engine

If the vehicle has a diesel engine, see
the Duramax diesel supplement.
