Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

15567102) - 2022 - CRC - 8/16/21

372

VEHICLE CARE

1. Remote Negative (

) Location. See

Jump Starting - North America

0

434

.

2. Positive (+) Terminal (Under Cover).

See

Jump Starting - North America

0

434

.

3.

Battery - North America

0

385

.

4.

Engine Compartment Fuse Block

0

392

.

5. Engine Oil Dipstick. See

Checking

Engine Oil

under

Engine Oil

0

372

.

6. Engine Cooling Fans (Out of View).

See

Cooling System

0

377

.

7. Engine Oil Fill Cap. See

When to

Add Engine Oil

under

Engine Oil

0

372

.

8. Coolant Surge Tank and Pressure

Cap. See

Cooling System

0

377

.

9.

Engine Air Cleaner/Filter

0

376

.

10. Brake Fluid Reservoir. See

Brake

Fluid

0

384

.

11. Windshield Washer Fluid Reservoir.

See

Adding Washer Fluid

under

Washer Fluid

0

382

.

Engine Oil

For diesel engine vehicles, see

Engine

Oil

in the Duramax diesel

supplement.

To ensure proper engine performance
and long life, careful attention must
be paid to engine oil. Following these
simple, but important steps will help
protect your investment:

.

Use engine oil approved to the
proper specification and of the
proper viscosity grade. See

Selecting the Right Engine Oil

in

this section.

.

Check the engine oil level regularly
and maintain the proper oil level.
See

Checking Engine Oil

and

When to Add Engine Oil

in this

section.

.

Change the engine oil at the
appropriate time. See

Engine Oil Life

System

0

374

.

.

Always dispose of engine oil
properly. See

What to Do with Used

Oil

in this section.

Checking Engine Oil

Check the engine oil level regularly,
every 650 km (400 mi), especially prior
to a long trip. The engine oil dipstick
handle is a loop. See

Engine

Compartment Overview

0

371

for the

location.

{

Warning

The engine oil dipstick handle may
be hot; it could burn you. Use a
towel or glove to touch the dipstick
handle.

If a low oil Driver Information Center
(DIC) message displays, check the oil
level.

Follow these guidelines:

.

To get an accurate reading, park the
vehicle on level ground. Check the
engine oil level after the engine has
been off for at least two hours.
Checking the engine oil level on
steep grades or too soon after
engine shutoff can result in
incorrect readings. Accuracy
