Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

15567102) - 2022 - CRC - 8/16/21

384

VEHICLE CARE

4. Select YES on the confirmation

message. Repeat for pads on the
other axle if they were also
replaced.

How to Disable the Brake Pad
Life System

The brake pad life system can be
turned off. This may be necessary if
aftermarket brake pads without wear
sensors are installed. When the
system is turned off, the front and
rear brake pad life percentages will
not display. However, the built-in wear
indicators that make a high-pitched
warning sound when the brake pads
are worn can still determine when the
pads should be replaced. See

Brakes

0

382

.

To turn off the brake pad life system:

1. Display Brake Pad Life on the DIC.

See

Driver Information Center (DIC)

0

132

.

2. Select the Brake Pad Life menu.
3. Select DISABLE.

To turn the brake pad life system back
on, follow the above steps but select
ENABLE in Step 2.

Brake Fluid

The brake master cylinder reservoir is
filled with GM approved DOT 4 brake
fluid as indicated on the reservoir cap.
See

Engine Compartment Overview

0

371

for the location of the reservoir.

Checking Brake Fluid

With the vehicle in P (Park) on a level
surface, the brake fluid level should be
between the minimum and maximum
marks on the brake fluid reservoir.

There are only two reasons why the
brake fluid level in the reservoir may
go down:

.

Normal brake lining wear. When
new linings are installed, the fluid
level goes back up.

.

A fluid leak in the brake hydraulic
system. Have the brake hydraulic
system fixed. With a leak, the
brakes will not work well.

Always clean the brake fluid reservoir
cap and the area around the cap
before removing it.

Do not top off the brake fluid. Adding
fluid does not correct a leak. If fluid is
added when the linings are worn,
there will be too much fluid when
new brake linings are installed. Add or
remove fluid, as necessary, only when
work is done on the brake hydraulic
system.

{

Warning

If too much brake fluid is added, it
can spill on the engine and burn,
if the engine is hot enough. You or
others could be burned, and the
vehicle could be damaged. Add
brake fluid only when work is done
on the brake hydraulic system.

When the brake fluid falls to a low
level, the brake warning light comes
on. See

Brake System Warning Light

0

124

.

Brake fluid absorbs water over time
which degrades the effectiveness of
the brake fluid. Replace brake fluid at
