386

VEHICLE CARE

1. Fill Plug
2. Drain Plug

If the level is below the bottom of the
fill plug (1) hole, located on the
transfer case, some lubricant will need
to be added. Add enough lubricant to
raise the level to the bottom of the fill
plug (1) hole. Use care not to
overtighten the plug.

What to Use

Refer to

Recommended Fluids and

Lubricants

0

461

to determine what

kind of lubricant to use.

Front Axle

When to Check Lubricant

It is not necessary to regularly check
the front axle fluid unless a leak is
suspected or an unusual noise is
heard. A fluid loss could indicate a
problem. Have it inspected and
repaired. This service can be complex.
See your dealer.

Do not directly power wash the
transfer case and/or front/rear axle
output seals. High pressure water can
overcome the seals and contaminate
the fluid. Contaminated fluid will
decrease the life of the transfer case
and/or drive axles and should be
replaced.

Rear Axle

When to Check Lubricant

It is not necessary to regularly check
the rear axle fluid unless a leak is
suspected or an unusual noise is
heard. A fluid loss could indicate a
problem. Have it inspected and
repaired. This service can be complex.
See your dealer.

Do not directly power wash the
transfer case and/or front/rear axle
output seals. High pressure water can
overcome the seals and contaminate
the fluid. Contaminated fluid will
decrease the life of the transfer case
and/or drive axles and should be
replaced.

Park Brake and P (Park)
Mechanism Check

{

Warning

When you are doing this check, the
vehicle could begin to move. You or
others could be injured and
property could be damaged. Make
sure there is room in front of the
vehicle in case it begins to roll. Be
ready to apply the regular brake at
once should the vehicle begin
to move.

Park on a fairly steep hill, with the
vehicle facing downhill. Keeping your
foot on the regular brake, set the
parking brake.
