394

VEHICLE CARE

Fuses

Usage

9

ELM 5

–

Exterior

Lighting Module 5

10

ELM 6

–

Exterior

Lighting Module 6

11

LRR/FRT SRR

–

Long Range Radar/
Front Short Range
Radar

12

–

13

Washer Front

14

Washer Rear

15

REC 2

–

Rear

Electrical Center 2

16

Power Sounder

17

EBCM

–

Electronic

Brake Control
Module Battery 1

19

DC/AC Inverter

20

IECR 2

–

Instrument

Electrical Center
Right 2

21

–

Fuses

Usage

22

IECL 1

–

Instrument

Electrical Center
Left 1

24

Fuel Heater

25

REC 1

–

Rear

Electrical Center 1

26

Camera Wash

27

Horn

28

Headlamp RT

–

Right

29

Headlamp LT

–

Left

30

ELM 3

–

Exterior

Lighting Module 3

31

ELM 1

–

Exterior

Lighting Module 1

32

–

33

Not R/C

34

–

37

MISC Body
Ignition 1

38

MISC Body
Ignition 2

Fuses

Usage

39

Upfitter

40

MISC Instrument
Panel (IP)

41

Trailer Parking
Lamps

42

Right Taillamp

44

Trailer Tow

45

Secondary Axle
Motor

46

Engine Control
Module (ECM)
Ignition

47

OBD Engine

48

–

49

Transmission
Auxiliary Oil Pump

50

A/C Clutch

51

TCCM

–

Transfer

Case Control Module

52

Front Wiper

53

–

54

Left Taillamps
