15567102) - 2022 - CRC - 8/16/21- Page 396

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

15567102) - 2022 - CRC - 8/16/21

VEHICLE CARE

395

Fuses

Usage

55

Trailer
Back-up Lamp

56

SADS

–

Semi Active

Damping System

57

Spare

58

Starter Motor

60

Powertrain Sensor 2

61

Automatic Lamp
Control (ALC) Main

62

ICCM/CVS/DEF

–

Integrated Chassis
Control Module/
Canister Vent
Solenoid/Diesel
Exhaust Fluid

63

Trailer Brake

65

–

66

Left Cool Fan Motor

67

AFM 2

–

Active Fuel

Management 2

68

Automatic Lamp
Control (ALC) Motor

69

Starter Pinion

Fuses

Usage

71

Cool Fan Motor
Lower

72

Right Cool Fan
Motor/Lower

73

Left Trailer Stop
Turn Lamp

74

TIM 2

–

Trailer

Interface Module 2

75

DEFC

–

Diesel

Exhaust Fluid
Controller

76

Electric Power
Running Boards

78

ECM

–

Engine

Control Module

79

Cabin Cool
Pump 17W

80

Powertrain Sensor 1

81

Right Trailer Stop
Turn Lamp

82

TIM 1

–

Trailer

Interface Module 1

83

FTZM

–

Fuel Tank

Zone Module

Fuses

Usage

84

Trailer Battery

85

Auxiliary
Water Pump

86

ECM

–

Engine

Control Module

87

Injector B Even

88

02 B Sensor

89

02 A Sensor

90

Injector A Odd

91

Engine Control
Module (ECM)
Throttle Control

92

Cool Fan Clutch
AERO Shutter

Relays

Usage

5

–

18

DC/AC Inverter

23

Fuel Heater

35

Trailer Park Lamp

36

Run/Crank
