Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

15567102) - 2022 - CRC - 8/16/21

VEHICLE CARE

397

There are relays on the back of the
fuse block. To access, press the tabs
and remove the fuse block.

The vehicle may not be equipped with
all of the fuses, relays, and features
shown.

Fuses

Usage

F1

Right Door

F2

Left Door

F3

Universal Garage Door
Opener (UGDO)/OnStar
Hands-free Calling
(OHC)/Camera

F4

BCM 2

Body Control

Module 2

F5

Displays

F6

Front Blower

F8

Left Door Panel

F10

Tilt/Column Lock

F11

DLC/ICM

Data Link

Connector/Column
Lock/Integrated Center
Stack

F12

Central Gateway
Module (CGM)/Onstar

Fuses

Usage

F14

Right Door Panel

F17

Steering Wheel Control

F18

F19

F20

F21

F22

Heated Wheel

F23

F24

F25

Special Equipment
Option (SEO)/
UPFITTER

F26

USB/Special Equipment
Option(SEO) Retained
Accessory Power (RAP)

F27

Auxiliary Power Outlet
(APO)/Retained
Accessory Power

F28

Fuses

Usage

F30

SDM/AOS/DMS/NVM

Sensing and Diagnostic
Module/Automatic
Occupant Sensing/
Driver Monitor System/
Night Vision Module

F31

BCM 3

Body Control

Module 3

F32

Center Stack Module
(CSM)/USB

F33

BCM 4

Body Control

Module 4

F34

Out of Park

F40

F41

F42

Electric Park Brake
Switch

F43

RSE/MFC

Rear Seat

Infotainment/Multi--
Functional Control

F44

F45

Radio Module

F46
