Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

15567102) - 2022 - CRC - 8/16/21

422

VEHICLE CARE

{

Warning

Changing a tire can be dangerous.
The vehicle can slip off the jack and
roll over or fall causing injury or
death. Find a level place to change
the tire. To help prevent the vehicle
from moving:

1. Set the parking brake firmly.

2. Shift the vehicle to P (Park).

3. For vehicles with four-wheel

drive with an N (Neutral)
transfer case position, be sure
the transfer case is in a drive
gear

not in N (Neutral).

4. Turn off the engine and do not

restart while the vehicle is
raised.

5. Do not allow passengers to

remain in the vehicle.

6. Place wheel blocks, if equipped,

on both sides of the tire at the
opposite corner of the tire
being changed.

When the vehicle has a flat tire (2),
use the following example as a guide
to assist in the placement of the
wheel blocks (1), if equipped.

1. Wheel Block (If Equipped)
2. Flat Tire

The following information explains
how to use the jack and change a tire.

Tire Changing

Before changing a flat tire, see

Hands-Free Operation

under

Liftgate

0

19

.

Removing the Spare Tire and
Tools

The equipment needed to change a
flat tire is stored in the rear of the
vehicle. The jacking tools are under

the load floor, secured with velcro
straps. The jack is behind a door in
the trim panel on the driver side.

1. Pull to open the trim panel door.

The third row driver side seat
may need to be folded to access
the trim panel door.
