Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

15567102) - 2022 - CRC - 8/16/21

VEHICLE CARE

433

4. Remove the flat tire secure strap

from the glove box and place the
loop end of the strap through the
cargo tie-down. Place the hook end
of the strap through the loop and
pull it until the strap is fastened
securely to the tie-down.

5. Route the hook end of the strap

through the wheel, as shown.

6. Attach the hook to the other cargo

tie-down in the rear of the vehicle.

7. Tighten the strap.

Full-Size Spare Tire

If this vehicle came with a full-size
spare tire, it was fully inflated when
new, however, it can lose air over
time. Check the inflation pressure
regularly. See

Tire Pressure

0

406

and

Vehicle Load Limits

0

240

for

information regarding proper tire
inflation and loading the vehicle. For

instructions on how to remove, install,
or store a spare tire, see

Tire Changing

0

422

.

If equipped with a temporary use
full-size spare tire, it is indicated on
the tire sidewall. See

Tire Sidewall

Labeling

0

402

This spare tire should

not be driven on over 112 km/h
(70 mph), or 88 km/h (55 mph) when
pulling a trailer, at the proper
inflation pressure. Repair and replace
the road tire as soon as it is
convenient, and stow the spare tire for
future use.

Caution

If the vehicle has four-wheel drive
and a different size spare tire is
installed, do not drive in four-wheel
drive until the flat tire is repaired
and/or replaced. The vehicle could
be damaged and the repairs would
not be covered by the warranty.
Never use four-wheel drive when a
different size spare tire is installed
on the vehicle.

Detailed Information for 2022 Cadillac escalade Owner Manual

Lists of information found in 2022 Cadillac escalade Owner Manual - Page 434

  • 4. Remove the flat tire secure strap from the glove box and place the loop end of the strap through the cargo tie-down.
  • 5. Route the hook end of the strap through the wheel, as shown.
  • 6. Attach the hook to the other cargo tie-down in the rear of the vehicle.
  • 7. Tighten the strap.
