Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

15567102) - 2022 - CRC - 8/16/21

VEHICLE CARE

437

10. Connect the other end of the

negative (

) cable to the discharged

battery negative (

) grounding

point.

11. Start the vehicle with the good

battery and run the engine for a
while.

12. Try to start the vehicle that had

the dead battery. If it will not start
after a few tries, it probably needs
service.

Caution

If the jumper cables are connected
or removed in the wrong order,
electrical shorting may occur and
damage the vehicle. The repairs
would not be covered by the vehicle
warranty. Always connect and
remove the jumper cables in the
correct order, making sure that the
cables do not touch each other or
other metal.

Jumper Cable Removal

Reverse the sequence exactly when
removing the jumper cables.

After starting the disabled vehicle and
removing the jumper cables, allow it
to idle for several minutes.

Towing the Vehicle

Caution

Incorrectly transporting a disabled
vehicle may cause damage to the
vehicle. Use proper tire straps to
secure the vehicle to the flatbed
tow truck. Do not strap or hook to
any frame, underbody,
or suspension component not
specified below. Do not move
vehicles with drive axle tires on the
ground. Damage is not covered by
the vehicle warranty.

Caution

The vehicle may be equipped with
an electric parking brake and/or an
electronic shifter. In the event of a
loss of 12-volt battery power, the
electric parking brake cannot be
released, and the vehicle cannot be

(Continued)

Caution (Continued)

shifted to N (Neutral). Tire skates
or dollies must be used under the
non-rolling tires to prevent damage
while loading/unloading the vehicle.
Dragging the vehicle will cause
damage not covered by the vehicle
warranty.

Caution

The vehicle may be equipped with a
tow eye. Improper use of the tow
eye may cause damage to the
vehicle and is not covered by the
vehicle warranty. If equipped, use
the tow eye to load the vehicle onto
a flatbed tow truck from a flat road
surface, or to move the vehicle a
very short distance at a walking
pace. The tow eye is not designed
for off-road recovery. The vehicle
must be in N (Neutral) with the
electric parking brake released
when using the tow eye.
