Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

15567102) - 2022 - CRC - 8/16/21

SEATS AND RESTRAINTS

53

Folding and Tumbling the Second
Row Seat from the Cargo Area

1. Second Row Power Seat Fold and

Tumble Switches

2. Third Row Power Seat Fold and

Raise Switches

To fold and tumble the seat from the
cargo area:

1. Make sure that there is nothing

under, in front of, or on the seat.

2. Press the switch (1) on the side

trim of the cargo area to fold the
second row seatback.

The left switch folds the left
seatback, and the right switch folds
the right seatback.

3. Press the switch again to release

the rear of the seat from the floor.
The seat will tumble forward.

The switches (2) can be used to fold
the third row seatbacks from the
cargo area. See

Third Row Seats

0

54

.

Returning the Seat to the Sitting
Position

{

Warning

If either seatback is not locked, it
could move forward in a sudden
stop or crash. That could cause
injury to the person sitting there.
Always push and pull on the
seatbacks to be sure they are
locked.

To return the seat to the sitting
position from the tumbled position:

1. Pull the seat down until it latches

to the floor. The seatback cannot
be raised if the seat is not latched
to the floor.

2. Lift the seatback and push it

rearward. Push and pull on the
seatback to make sure it is locked.

3. For the 60/40 split-bench seat,

make sure the seat belt in the
center seating position is not
caught between the two seats and
is not twisted.

Heated Rear Seats

{

Warning

If temperature change or pain to
the skin cannot be felt, the seat
heater may cause burns. See the
Warning under

Heated and

Ventilated Front Seats

0

47

.
