Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

15567102) - 2022 - CRC - 8/16/21

74

SEATS AND RESTRAINTS

2. Remove any additional material

from the seat, such as blankets,
cushions, seat covers, seat heaters,
or seat massagers.

3. Place the seatback in the fully

upright position.

4. Have the person sit upright in the

seat, centered on the seat cushion,
with legs comfortably extended.

5. If the shoulder portion of the belt

is pulled out all the way, the child
restraint locking feature will be
engaged. This may unintentionally
cause the passenger sensing system
to turn the airbag off for some
adult-sized occupants. If this
happens, unbuckle the belt, let the
belt go back all the way, and then
buckle the belt again without
pulling the belt out all the way.

6. Restart the vehicle and have the

person remain in this position for
two to three minutes after the ON
indicator is lit.

{

Warning

If the front outboard passenger
airbag is turned off for an
adult-sized occupant, the airbag will
not be able to inflate and help
protect that person in a crash,
resulting in an increased risk of
serious injury or even death. An
adult-sized occupant should not
ride in the front outboard passenger
seat, if the passenger airbag OFF
indicator is lit.

Additional Factors Affecting
System Operation

Seat belts help keep the passenger in
position on the seat during vehicle
maneuvers and braking, which helps
the passenger sensing system
maintain the passenger airbag status.
See

Seat Belts

and

Child Restraints

in the Index for additional
information about the importance of
proper restraint use.

A thick layer of additional material,
such as a blanket or cushion,
or aftermarket equipment such as seat
covers, seat heaters, and seat

massagers can affect how well the
passenger sensing system operates.
We recommend that you not use seat
covers or other aftermarket equipment
except when approved by GM for your
specific vehicle. See

Adding Equipment

to the Airbag-Equipped Vehicle

0

75

for

more information about modifications
that can affect how the system
operates.

The ON indicator may be lit if an
object, such as a briefcase, handbag,
grocery bag, laptop, or other electronic
device, is put on an unoccupied seat.
If this is not desired, remove the
object from the seat.

{

Warning

Stowing articles under the
passenger seat or between the
passenger seat cushion and
seatback may interfere with the
proper operation of the passenger
sensing system.
