Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-15555985) - 2022 - CRC - 8/3/21

Instruments and Controls

129

OUTPUT shows the power output to the
trailer any time a trailer with electric brakes
is connected. Output is displayed as a bar
graph. Dotted lines may appear in the
OUTPUT display if a trailer is not connected.

Off Road :

If equipped, displays vehicle pitch

and roll information, road wheel angle, and
four-wheel drive (4WD) status. If the vehicle
has low traction, a low traction indicator
and the wheels affected will display amber
in the Off-Road page.

Engine Hours (Hourmeter) :

Shows the total

number of hours the engine has run. This
display also shows the engine idle hours.

Average Speed :

Displays the average

vehicle speed in kilometers per hour (km/h)
or miles per hour (mph). This average is
based on the various vehicle speeds
recorded since the last reset. Reset the
average speed by pressing the thumbwheel
while this display is active to show a
confirmation window to select Yes or No.

Transmission Fluid Temperature :

Shows the

temperature of the automatic transmission
fluid in either degrees Celsius (°C) or degrees
Fahrenheit (°F).

Coolant Temperature :

Shows the engine

coolant temperature in either degrees
Celsius (°C) or degrees Fahrenheit (°F).

Oil Temperature :

Shows the engine oil

temperature in either degrees Celsius (°C) or
degrees Fahrenheit (°F).

Oil Pressure :

Shows the current oil pressure

in either kilopascal (kPa) or in pounds per
square inch (psi).

Info Page Options :

Scroll to choose which

info pages appear on the DIC. Press the
thumbwheel to select or deselect.

Blank Page :

Shows no information.

Head-Up Display (HUD)

{

Warning

If the HUD image is too bright or too
high in your field of view, it may take
you more time to see things you need to
see when it is dark outside. Be sure to
keep the HUD image dim and placed low
in your field of view.

If equipped with HUD, some information
about the operation of the vehicle is
projected onto the windshield. The image is
projected through the HUD lens on top of

the instrument panel. The information
appears as an image focused out toward the
front of the vehicle.

Caution

If you try to use the HUD image as a
parking aid, you may misjudge the
distance and damage your vehicle. Do not
use the HUD image as a parking aid.

The HUD information can be displayed in
various languages. The speedometer reading
and other numerical values can be displayed
in either English or metric units.

The language selection is changed through
the radio, and the units of measurement is
changed through the instrument cluster. See

Settings (Uplevel Radio)

0

183

or

Settings (Base Radio)

0

186

and

Options

under

Instrument Cluster (Base Level)

0

102

or

Instrument Cluster (Uplevel)

0

105

.
