Vehicle Care- Page 338

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-15555985) - 2022 - CRC - 8/3/21

Vehicle Care

337

Fuses

Usage

9

ELM 5

–

Exterior

Lighting Module 5

10

ELM 6

–

Exterior

Lighting Module 6

11

Spare

12

–

13

Washer Front

14

Washer Rear

15

REC 2

–

Rear Electrical

Center 2

16

Power Sounder

17

Spare

19

DC/AC Inverter

20

IECR 2

21

–

22

IECL 2

24

EBCM

–

Electronic Brake

Control Module

25

REC 1

–

Rear Electrical

Center 1

26

Camera Wash

Fuses

Usage

27

Horn

28

Headlamp RT

–

Right

29

Headlamp LT

–

Left

30

ELM 3

–

Exterior

Lighting Module 3

31

ELM 1

–

Exterior

Lighting Module 1

32

–

33

Not R/C

34

–

37

On Board Diagnostics
(OBD) Body

38

MISC Body

39

Upfitter

40

MISC Instrument
Panel (IP)

41

Trailer Parking Lamps

42

Right Taillamp

44

Trailer Tow

45

Secondary Axle Motor

Fuses

Usage

46

Engine Control Module
(ECM) Ignition

47

OBD Engine

48

–

49

TCM

–

Telematics

Control Module

50

A/C Clutch

51

TCCM

–

Transfer Case

Control Module

52

Front Wiper

53

–

54

Left Taillamps

55

Trailer Back-up Lamp

56

SADS

–

Semi Active

Damping System

57

Spare

58

Starter Motor

60

AFM 1

–

Active Fuel

Management 1

61

Automatic Lamp Control
(ALC) Main
