Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-15555985) - 2022 - CRC - 8/3/21

Vehicle Care

339

Instrument Panel Fuse Block

The right instrument panel fuse block access
door is on the passenger side edge of the
instrument panel.

Pull off the cover to access the fuse block.
A fuse puller is available on the right
instrument panel end cap.

There are relays on the back of the fuse
block. To access, press the tabs and remove
the fuse block.

The vehicle may not be equipped with all of
the fuses, relays, and features shown.

Fuses

Usage

F1

Right Door
