Vehicle Care

341

Fuses

Usage

F56

DC/DC CNV BATT 1

–

Direct

Current/Direct Current
Converter Battery 1

F57

DC/DC CNV BATT 2

–

Direct

Current/Direct Current
Converter Battery 2

F58

Spare

F59

–

Circuit

Breakers

Usage

CBO1

APO 1

–

Auxiliary Power

Outlet 1

CBO2

APO 2

–

Auxiliary Power

Outlet 2

Relays

Usage

K1

–

K2

RAP/ACCY 1

–

Retain

Accessory Power/
Accessory 1

K4

RAP/ACCY 2

–

Retain

Accessory Power/
Accessory 2

Relays

Usage

K5

–

Rear Compartment Fuse Block

The rear compartment fuse block is behind
the access panel on the left side of the
compartment.

Pull the panel out by grabbing the finger
access slot at the rear edge.

The vehicle may not be equipped with all of
the fuses, relays, and features shown.
