Front Panel(s) Installation With Rear Hard Top
Removed
1. Turn the left and right panels over and move the spacer
block (located on the rear of the panel) upward 90
degrees.
NOTE:
The front panel(s) must be positioned properly to
ensure sealing. Set the panels on the windshield frame so
that there is no overhang. Also, make sure that the panels
are sitting flush with the body.
2. Install the right panel first, then the left panel.
3. Reinstall the panel(s) using the same steps for removal
in reverse order.
Rear Hard Top Removal
1. Remove both front panels. Refer to “Front Panel(s)
Removal” in this section.
2. Open both doors.
3. Remove the two Torx head screws that secure the hard
top at the B-pillar (near the top of the door) using a #40
Torx head driver (Four–Door Only).
4. Remove the six Torx head screws that secure the hard
top to the vehicle (along the interior bodyside) using a
#40 Torx head driver.
Step One
88
GETTING TO KNOW YOUR VEHICLE
