10. Close the swing gate.
11. Remove the hard top from the vehicle. Place the hard
top on a soft surface to prevent damage.
CAUTION!
The removal of the Freedom Top requires four adults
located on each corner. Failure to follow this caution
could damage the Freedom Top.
Rear Hard Top Installation
NOTE:
If the door frames are installed from soft top usage,
they must be removed prior to installation of the hard top.
1. Inspect the hard top seals for damage and replace if
necessary.
2. Install the hard top using the same steps for removal in
reverse order.
Make sure that the hard top is sitting flush with the body
at the sides and check to ensure that there is a uniform gap
between the lift glass and hard top.
NOTE:
•
The Torx fasteners that attach the hard top to the body
should be torqued to 88 in lb +/- 22 in lb (10 N·m +/-
2.5 N·m).
•
It is not necessary to pinch connection when reinstall-
ing washer hose. Push on until click is heard.
Pinch Grip On Hose
3
GETTING TO KNOW YOUR VEHICLE
91
