GENERAL

L3560, L4060, L4760, L5060, L5460, L6060, WSM

G-80

10. IMPLEMENT LIMITATIONS

The KUBOTA Tractor has been thoroughly tested for proper performance with implements sold or approved by

KUBOTA. Use with implements which exceed the maximum specifications listed below, or which are otherwise unfit

for use with the KUBOTA Tractor may result in malfunctions or failures of the tractor, damage to other property and

injury to the operator or others. [Any malfunctions or failures of the tractor resulting from use with improper implements

are not covered by the warranty.]

NOTE

• Implement size may vary depending on soil operating conditions.

9Y1210824GEG0129US0

Tread (max. width)

Lower link end max.

loading weight W0

Front

Rear

L3560

1155 mm (45.5 in.)

1480 mm (58.3 in.)

1700 kg (3750 lbs)

L4060

1530 mm (60.2 in.)

1750 kg (3860 lbs)

L4760

1300 mm (51.2 in.)

L5060, L5460, L6060

1340 mm (52.8 in.)

1430 mm (56.3 in.)

Actual figures

Implement weight W1

and / or size

Max. Drawbar Load W2

Trailer loading weight

W3 Max. capacity

L3560

As in the following list

(Shown on the next pate)

650 kg (1430 lbs)

2000 kg (4400 lbs)

L4060

2500 kg (5500 lbs)

L4760, L5060

L5460, L6060

3000 kg (6600 lbs)

Lower link end max. hydraulic lift capacity:

W0

Implement weight: The implement weight which you can put on the link:

W1

Max. drawbar load:

W2

Trailer loading weight: The max loading weight for trailer (without trailer weight):

W3

KiSC issued 03, 2016 A
