ENGINE

L3560, L4060, L4760, L5060, L5460, L6060, WSM

1-M1

1. FEATURES

The engine models shown in the table below are

adopted in the L60 series tractor.

9Y1210824ENM0001US0

Tractor Model

Engine Model

L3560

D1803-CR-E4

L4060

V2403-CR-E4

L4760

V2403-CR-E4

L5060

V2403-CR-TE4

L5460

V2403-CR-TE4

L6060

V2403-CR-TE4

KiSC issued 03, 2016 A
