Atmosphere Pressure Sensor

An atmosphere pressure sensor is installed in the

body of the ECU and detects atmospheric pressure

close to the ECU.

This is provided to prevent changes to combustion

status due to changes in atmospheric pressure. (At high

altitudes, air pressure is low and air volume is low

making complete combustion difficult etc.)

NOTE

• Since the atmospheric pressure sensor has not

been adopted as a part, replace the ECU
assembly when the atmospheric pressure is
needed to replace.

9Y1210824ENM0034US0

(1) Atmosphere Pressure

Sensor

KiSC issued 03, 2016 A
