ENGINE

L3560, L4060, L4760, L5060, L5460, L6060, WSM

1-M25

(2)  PM Warning Level (Inhibit Version)

PM warning level 0 to 5 as shown below is set according to the amount of accumulated PM to prompt the operator

to perform the required procedure in each level.

• Level 0: Normal operation. Regeneration is not required.

• Level 1: Auto Regeneration is possible in the Auto Regeneration Mode.

• Level 2: Auto Regeneration is possible in the Auto Regeneration Mode. Parked Regeneration is possible in both

of the Auto Regeneration Mode and Inhibit Mode.

• Level 3: Auto Regeneration is not possible in above level 3. Parked Regeneration is required as soon as possible.

• Level 4: Only by using diagmaster, Parked Regeneration is possible. Parked Regeneration is required as soon

as possible.

• Level 5: Cleaning or replacement is required. Regeneration is not possible.

9Y1210824ENM0059US0

Auto Regeneration Mode



 : Blink,



 : ON

9Y1210824ENM0060US0

Warning

level

Buzzer

Engine

output

limitation

Remark

Level 0

No

No

limitation



Normal operation, Regeneration is not required.

Level 1

No

No

limitation







Condition for Auto Regeneration is not satisfied and engine

speed is low.





Condition for Auto Regeneration is not satisfied. Engine

speed is OK.





Under the Auto Regeneration.







Under the Auto Regeneration. Engine speed is low. (Auto

Regeneration may be interrupted after a while.)

Level 2-1: Every 5

seconds

Level 2-2: Every 3

seconds.

No

limitation

Same with level 1



Auto Regeneration is same with level 1. Condition for

Parked Regeneration is not satisfied.











Condition for Parked Regeneration is satisfied. When

pressing the parked regeneration switch, Parked

Regeneration will start.







Under the Parked Regeneration.

Level 3

Every

second

50 %





Condition for Parked Regeneration is not satisfied.







Condition for Parked Regeneration is satisfied. When

pressing the parked regeneration switch, Parked

Regeneration will start.







Under the Parked Regeneration.

Level 4

Every

second

50 %



Without diagmaster.

Same with level 3



When using diagmaster and selecting the Parked

Regeneration command.

Level 5

Every

second

50 %



Even when using diagmaster, it is not possible to carry out

Parked Regeneration.
