(2)  PM Warning Level (Default Version)

PM warning level 0 to 5 as shown below is set according to the amount of accumulated PM to prompt the operator

to perform the required procedure in each level.

• Level 0: Normal operation. Regeneration is not required.

• Level 1: Auto Regeneration is possible in the Auto Regeneration Mode.

• Level 2: Auto Regeneration is possible in the Auto Regeneration Mode. Parked Regeneration is possible in both

of the Auto Regeneration Mode and Inhibit Mode.

• Level 3: Auto Regeneration is not possible in above level 3. Parked Regeneration is required as soon as possible.

• Level 4: Only by using diagmaster, Parked Regeneration is possible. Parked Regeneration is required as soon

as possible.

• Level 5: Cleaning or replacement is required. Regeneration is not possible.

9Y1210824ENM0064US0

Auto Regeneration Mode

 : Blink,

 : ON

9Y1210824ENM0065US0

Warning

level

Buzzer

Engine

output

limitation

Remark

0

No

No

limitation

Normal operation, Regeneration is not required.

1

No

No

limitation

Condition for Auto Regeneration is not satisfied and engine

speed is low.

DPF temperature for Auto Regeneration is not satisfied.

Engine speed is OK.

Under the Auto Regeneration.

Level 2-1: Every 5

second

Level 2-2: Every 3

second

No

limitation

Condition for Auto Regeneration is not satisfied and engine

speed is low.

DPF temperature for Auto Regeneration is not satisfied.

Engine speed is OK.

Under the Parked Regeneration.

3

Every

second

50 %

Condition for Parked Regeneration is not satisfied.

Condition for Parked Regeneration is satisfied. When

pressing the parked regeneration switch, Parked

Regeneration will start.

Under the preparation for Parked Regeneration.

Under the Parked Regeneration.

4

Every

second

50 %

Without diagmaster.

When using diagmaster and condition for Parked

Regeneration is not satisfied.

This indication switch to the following if cancel the DPF

INHIBIT switch in the state of condition for Parked

Regeneration is satisfied.

When using diagmaster and condition for Parked

Regeneration is satisfied. When pressing the parked

regeneration switch, Parked Regeneration will start.

Under the preparation for Parked Regeneration when using

diagmaster.

Under the Parked Regeneration when using diagmaster.

5

Every

seconds

50 %

Even when using diagmaster, it is not possible to carry out

Parked Regeneration.
