Inhibit Mode; Warning ; Engine - Page 143

ENGINE

L3560, L4060, L4760, L5060, L5460, L6060, WSM

1-M28

Inhibit Mode



 : Blink,



 : ON

9Y1210824ENM0066US0

Warning

level

Buzzer

Engine

output

limitation

Remark

0

No

No

limitation



Normal operation, Regeneration is not required.

1

No

No

limitation





Regeneration is required, but Auto Regeneration is not

permitted.

Parking Regeneration is not possible.

Level 2-1: Every 5

second

Level 2-2: Every 3

second

No

limitation







Auto Regeneration is prohibited. Condition for Parked

Regeneration is not satisfied.

This indication switch to the following if cancel the DPF

INHIBIT switch in the state of condition for Parked

Regeneration is satisfied. Shift to the Auto Regeneration if

cancel the DPF INHIBIT switch in the state of condition for

Parked Regeneration is not satisfied.









Condition for Parked Regeneration is satisfied. When

pressing the parked regeneration switch, Parked

Regeneration will start.









Under the preparation for Parked Regeneration.





Under the Parked Regeneration.

3

Every

seconds

50 %







This indication switch to the following if cancel the DPF

INHIBIT switch in the state of condition for Parked

Regeneration is satisfied.







Condition for Parked Regeneration is satisfied. When

pressing the parked regeneration switch, Parked

Regeneration will start.







Under the preparation for Parked Regeneration.







Under the Parked Regeneration.

4

Every

seconds

50 %





Without diagmaster.







When using diagmaster and condition for Parked

Regeneration is not satisfied.

This indication switch to the following if cancel the DPF

INHIBIT switch in the state of condition for Parked

Regeneration is satisfied.







When using diagmaster and condition for Parked

Regeneration is satisfied. When pressing the parked

regeneration switch, Parked Regeneration will start.







Under the preparation for Parked Regeneration when using

diagmaster.







Under the Parked Regeneration when using diagmaster.

5

Every

seconds

50 %





Even when using diagmaster, it is not possible to do Parked

Regeneration.
