ENGINE

L3560, L4060, L4760, L5060, L5460, L6060, WSM

1-M31

Differential Pressure Sensor

The differential pressure sensor is a sensor that

detects the pressure differential between the inlet and

the outlet of the DPF.

The engine ECU calculates the amount of

accumulated PM in the DPF using this signal.

9Y1210824ENM0048US0

Oil Separator

Removes oil in the blowby gases that pass through

the element (1) and the oil is returned to the oil pan.

Blowby gases that pass through the element (1) are

mixed into the intake upstream from the turbocharger.

9Y1210824ENM0049US0

(1) Differential Pressure Sensor

(1) Element
