ENGINE

L3560, L4060, L4760, L5060, L5460, L6060, WSM

1-S9

COOLING SYSTEM

9Y1210824ENS0002US0

Item

Factory Specification

Allowable Limit

Fan Belt

Tension

7.0 to 9.0 mm (0.28 to

0.35 in.) deflection at

98 N (10 kgf, 22 lbf) of

force

–

Thermostat Valve

Opening-

Temperature

(When the valve

starts to open)

Opening-

Temperature

(When the valve

opened

completely)

80.5 to 83.5 °C

176.9 to 182.3 °F

95 °C

203 °F

–

–

Radiator

Water Tightness

No leak at

specified pressure

–

Radiator Cap

Pressure

Decreasing Time

More than 10 seconds

for pressure decrease

from 90 to 60 kPa

from 0.9 to 0.6 kgf/cm

2

from 10 to 9 psi

–

KiSC issued 03, 2016 A
