ENGINE

L3560, L4060, L4760, L5060, L5460, L6060, WSM

1-S10

3. TIGHTENING TORQUES

Tightening torques of screws, bolts and nuts on the table below are especially specified.

(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.)

Tractor

Item

N·m

kgf·m

lbf·ft

Filter comp (DPF) mounting clamp band

16 to 20

1.7 to 2.0

12 to 14

Temperature sensor

25 to 34

2.5 to 3.5

18 to 25

Differential pressure pipe

16 to 22

1.6 to 2.3

12 to 16

Joint bolt for PTO delivery pipe

35 to 39

3.5 to 4.0

26 to 28

Engine and clutch housing mounting screw

78 to 90

7.9 to 9.2

58 to 66

Engine and clutch housing mounting nut

103 to 117

10.5 to 12.0

76.0 to 86.7

Joint bolt for power steering delivery pipe

40 to 49

4.0 to 5.0

29 to 36

Retaining nut of power steering delivery pipe

49 to 58

5.0 to 6.0

37 to 43

Joint bolt for HST return pipe (HST type)

88 to 98

9.0 to 9.9

65 to 72

Front axle frame mounting screw (7T)

78 to 90

7.9 to 9.2

58 to 66

Front axle frame mounting screw (9T)

103 to 117

10.5 to 12.0

76.0 to 86.7

Muffler pipe mounting screw

31 to 37

3.2 to 3.7

23 to 27

Exhaust flange mounting screw

31 to 37

3.2 to 3.7

23 to 27

Front loader pipe retaining nut

90 to 108

9.18 to 11.0

66.4 to 79.6

Clutch mounting screw

24 to 27

2.4 to 2.8

18 to 20

Outer roof mounting screw (CABIN type only)

3.5 to 4.0

0.36 to 0.40

2.6 to 2.9

Cabin mounting bolt and nut (CABIN type only)

12.4 to 14.7

12.6 to 15.0

91.2 to 108

KiSC issued 03, 2016 A
