ENGINE

L3560, L4060, L4760, L5060, L5460, L6060, WSM

1-S11

ENGINE

NOTE

• For the screws, bolts and nuts with the mark "*", apply engine oil to their threads and seats before you

tighten.

• The alphabet "M" in Dimension × Pitch shows that the screw, bolt or nut dimensions are in the metric

system. The dimension is the nominal external diameter in mm of the threads. The pitch is the nominal
distance in mm between 2 threads.

9Y1210824ENS0003US0

Item

Dimension ×

Pitch

N·m

kgf·m

lbf·ft

Injector clamp screw

M8 × 1.25

24 to 27

2.4 to 2.8

18 to 20

Cylinder head cover screw

M6 × 1.0

6.86 to 11.3

0.700 to 1.15

5.06 to 8.33

Injection pipe retaining nut

M12 × 1.5

24.5 to 29.4

2.50 to 2.99

18.1 to 21.6

Oil pressure switch screw

R 1/8

15 to 19

1.5 to 2.0

11 to 14

Supply pump mounting nut

M8 × 1.25

24 to 27

2.4 to 2.8

18 to 20

Common rail mounting screw

M8 × 1.25

24 to 27

2.4 to 2.8

18 to 20

Coolant temperature sensor taper

screw

16 to 23

1.6 to 2.4

12 to 17

Camshaft position sensor mounting

screw

4 to 5

0.4 to 0.6

3 to 4

Crankshaft position sensor mounting

screw

4 to 6

0.4 to 0.6

3 to 4

Rocker arm bracket screw

M8 × 1.25

24 to 27

2.4 to 2.8

18 to 20

*Cylinder head mounting screw

M11 × 1.25

93.2 to 98.0

9.50 to 10.0

68.8 to 72.3

Oil cooler joint screw

M20 × 1.5

40 to 44

4.0 to 4.5

29 to 32

Fan drive pulley mounting nut

M30 × 1.5

138 to 156

14.0 to 16.0

102 to 115

Camshaft set screw

M8 × 1.25

24 to 27

2.4 to 2.8

18 to 20

Balancer shaft set bolt

M8 × 1.25

24 to 27

2.4 to 2.8

18 to 20

*Connecting rod screw

M8 × 1.25

40 to 45

4.1 to 4.5

30 to 33

*Flywheel screw

M12 × 1.25

98.1 to 107

10.0 to 11.0

72.4 to 79.5

Screw 1 of main bearing case

M9 × 1.25

46 to 50

4.7 to 5.2

34 to 37

Screw 2 of main bearing case

M10 × 1.25

69 to 73

7.0 to 7.5

51 to 54

B

 terminal nut of starter

M8 × 1.25

5.9 to 11

0.60 to 1.2

4.4 to 8.6

Pulley nut of alternator

58.4 to 78.9

5.95 to 8.05

43.1 to 58.2

Diesel Particulate Filter (hereinafter

referred to as the "DPF") stay 1

M10 × 1.25

49 to 55

5.0 to 5.7

37 to 41

Boost sensor mounting screw

M4 × 0.7

0.98 to 1.7

0.10 to 0.18

0.73 to 1.3

Glow lead mounting nut

M4 × 0.7

0.98 to 1.7

0.10 to 0.18

0.73 to 1.3

Glow plug

M10 × 1.25

15 to 19

1.5 to 2.0

11 to 14

Injector clamp bolt

M8 × 1.25

23.5 to 27.5

2.40 to 2.80

17.4 to 20.2

Injection pipe cap nut

M12 × 1.5

24.5 to 29.4

2.5 to 3.0

18.1 to 21.6

Mounting screw of bearing case cover

M8 × 1.25

24 to 27

2.4 to 2.8

18 to 20

KiSC issued 03, 2016 A
