INFORMATION

L3560, L4060, L4760, L5060, L5460, L6060, WSM

I-11

[2] GST

NOTE

•

*Manufacturer's estimate
The company reserve the right to change the specifications without notice.

9Y1210824INI0009US0

Model

L3560

L4060

L4760

L5060

4WD

Engine

Model

D1803-CR-E4

V2403-CR-E4

V2403-CR-TE4

Type

Direct injection vertical, water-cooled, 4-cycle diesel

Number of cylinders

3

4

Total displacement

1.826 L (111.4 cu.in.)

2.434 L (148.5 cu.in.)

Bore and stroke

87 × 102.4 mm (3.4 × 4.0 in.)

Rated revolution

2700 min

-1

 (rpm)

Low idling revolution

800 min

-1

 (rpm)

Net power*

26.1 kW (35.0 HP)

29.8 kW (40.0 HP)

35.1 kW (47.0 HP)

37.3 kW (50.0 HP)

PTO power*

(factory observed)

22.0 kW (29.5 HP) /

2700 min

-1

 (rpm)

25.4 kW (34.0 HP) /

2700 min

-1

 (rpm)

30.6 kW (41.0 HP) /

2700 min

-1

 (rpm)

32.8 kW (44.0 HP) /

2700 min

-1

 (rpm)

Maximum torque

114.1 N·m (84.2 lbf·ft)

133.5 N·m

(98.5 lbf·ft)

157.4 N·m

(116.1 lbf·ft)

164.2 N·m

(121.1 lbf·ft)

Battery capacity

12 V, RC: 133 min, CCA: 582 A

Capacities

Fuel tank

51 L (13.5 U.S.gals, 11.2 Imp.gals)

Engine crankcase (with filter)

6.7 L (7.1 U.S.qts,

5.9 Imp.qts)

8.2 L (8.7 U.S.qts, 7.2 Imp.qts)

9.4 L (9.9 U.S.qts,

8.3 Imp.qts)

Engine coolant

7.5 L (7.9 U.S.qts, 6.6 Imp.qts)

8.2 L (8.7 U.S.qts, 7.2 Imp.qts)

Transmission case

42 L (11.1 U.S.gals,

9.24 Imp.gals)

43 L (11.4 U.S.gals, 9.46 Imp.gals)

45 L (11.9 U.S.gals,

9.9 Imp.gals)

Dimensions

Overall length (without 3p)

2920 mm (115.0 in.)

3085 mm (121.5 in.)

3210 mm (126.4 in.)

Overall width (min. tread)

1520 mm (59.8 in.)

1690 mm (66.5 in.)

1710 mm (67.3 in.)

Overall height (with ROPS)

2470 mm (97.2 in.)

2480 mm (97.6 in.)

2490 mm (98.0 in.)

Wheel base

1805 mm (71.1 in.)

1895 mm (74.6 in.)

1915 mm (75.4 in.)

Min. ground clearance

342 mm (13.5 in.)

360 mm (14.2 in.)

392 mm (15.4 in.)

Tread

Front

1155 mm (45.5 in.)

1300 mm (51.2 in.)

1340 mm (52.8 in.)

Rear

1200 mm (47.2 in.),

1300 mm (51.2 in.),

1385 mm (54.5 in.),

1480 mm (58.3 in.)

1285 mm (50.6 in.),

1435 mm (56.5 in.),

1530 mm (60.2 in.)

1325 mm (52.2 in.),

1430 mm (56.3 in.)

Weight (with ROPS)

1610 kg (3549 lbs)

1655 kg (3649 lbs)

1675 kg (3693 lbs)

1780 kg (3924 lbs)

Traveling

system

Standard tire

size

Front

7-16

8.3-16

9.5-16

Rear

12.4-24

14.9-24

14.9-26

Clutch

Dry type single stage

Steering

Hydrostatic power steering

Transmission

Glide shift transmission (12 forward and 8 reverse speeds)

Braking system

Wet disk type

Min. turning radius

(with brake)

2.7 m (8.9 feet)

2.8 m (9.2 feet)

Hydraulic unit

Hydraulic control system

Position control

Pump capacity

31.5 L (8.3 U.S.gals,

6.9 Imp.gals)

37.0 L (9.8 U.S.gals, 8.1 Imp.gals)

Three point hitch

SAE category 1

SAE category 1, 2

Max. lift force

At lift points

1700 kg (3750 lbs)

1750 kg (3860 lbs)

24 in. behind

lift points

1200 kg (2650 lbs)

1250 kg (2760 lbs)

1350 kg (2980 lbs)

System pressure

17.7 MPa (180 kgf/cm

2

, 2560 psi)

PTO

Rear PTO

SAE 1-3/8, 6 splines

PTO/Engine speed

540 min

-1

 (rpm) / 2550 min

-1

 (rpm)

KiSC issued 03, 2016 A
