[4] HST with CABIN TYPE- Page 20

INFORMATION

L3560, L4060, L4760, L5060, L5460, L6060, WSM

I-14

[4]  HST with CABIN TYPE

Model

L3560

L4060

L4760

L5460

L6060

4WD

Engine

Model

D1803-CR-E4

V2403-CR-E4

V2403-CR-TE4

Type

Direct injection vertical, water-cooled, 4-cycle diesel

Number of cylinders

3

4

Total displacement

1.826 L

(111.4 cu.in.)

2.434 L (148.5 cu.in.)

Bore and stroke

87 × 102.4 mm (3.4 × 4.0 in.)

Rated revolution

2600 min

-1

 (rpm)

Low idling revolution

800 min

-1

 (rpm)

Net power*

26.1 kW

(35.0 HP)

29.8 kW

(40.0 HP)

35.1 kW

(47.0 HP)

40.3 kW

(54.0 HP)

44.8 kW

(60.0 HP)

PTO power*

(factory observed)

20.9 kW

(28.0 HP) /

2600 min

-1

 (rpm)

24.2 kW

(32.5 HP) /

2600 min

-1

 (rpm)

29.5 kW

(39.5 HP) /

2600 min

-1

 (rpm)

34.7 kW

(46.5 HP) /

2600 min

-1

 (rpm)

39.5 kW

(53.0 HP) /

2600 min

-1

 (rpm)

Maximum torque

114.1 N·m

(84.2 lbf·ft)

133.5 N·m

(98.5 lbf·ft)

157.4 N·m

(116.1 lbf·ft)

182.6 N·m

(134.7 lbf·ft)

195.6 N·m

(144.3 lbf·ft)

Battery capacity

12 V, RC: 133 min, CCA: 582 A

Capacities

Fuel tank

51 L (13.5 U.S.gals, 11.2 Imp.gals)

Engine crankcase (with filter)

6.7 L

(7.1 U.S.qts,

5.9 Imp.qts)

8.2 L (8.7 U.S.qts, 7.2 Imp.qts)

9.4 L (9.9 U.S.qts, 8.3 Imp.qts)

Engine coolant

7.5 L (7.9 U.S.qts, 6.6 Imp.qts)

8.2 L (8.7 U.S.qts, 7.2 Imp.qts)

Transmission case

42 L

(11.1 U.S.gals,

9.24 Imp.gals)

43 L (11.4 U.S.gals, 9.46 Imp.gals)

45 L (11.9 U.S.gals, 9.9 Imp.gals)

Dimensions

Overall length (without 3p)

2920 mm

(115.0 in.)

3085 mm (121.5 in.)

3210 mm (126.4 in.)

Overall width (min. tread)

1520 mm

(59.8 in.)

1690 mm (66.5 in.)

1710 mm (67.3 in.)

Overall height

2300 mm

(90.6 in.)

2315 mm (91.1 in.)

2350 mm (92.5 in.)

Wheel base

1805 mm

(71.1 in.)

1895 mm (74.6 in.)

1915 mm (75.4 in.)

Min. ground clearance

342 mm (13.5 in.)

360 mm (14.2 in.)

392 mm (15.4 in.)

Tread

Front

1155 mm (45.5 in.)

1300 mm

(51.2 in.)

1340 mm (52.8 in.)

Rear

1200 mm

(47.2 in.),

1300 mm

(51.2 in.),

1385 mm

(54.5 in.),

1480 mm

(58.3 in.)

1285 mm (50.6 in.),

1435 mm (56.5 in.),

1530 mm (60.2 in.)

1325 mm (52.2 in.),

1430 mm (56.3 in.)

Weight (with CABIN)

1760 kg

(3880 lbs)

1875 kg

(4134 lbs)

1915 kg

(4222 lbs)

1980 kg (4365 lbs)

Traveling

system

Standard tire

size

Front

7-16

8.3-16

9.5-16

Rear

12.4-24

14.9-24

14.9-26

Clutch

–

Steering

Hydrostatic power steering

Transmission

Hydrostatic transmission (3 speeds)

Braking system

Wet disk type

Min. turning radius

(with brake)

2.7 m (8.9 feet)

2.8 m (9.2 feet)

KiSC issued 03, 2016 A
