background image

INFORMATION

L3560, L4060, L4760, L5060, L5460, L6060, WSM

I-15

NOTE

•

*Manufacturer's estimate
The company reserve the right to change the specifications without notice.

9Y1210824INI0011US0

Hydraulic unit

Hydraulic control system

Position control

Pump capacity

30.4 L

(8.0 U.S.gals,

6.7 Imp.gals)

35.6 L (9.4 U.S.gals, 7.8 Imp.gals)

Three point hitch

SAE category 1

SAE category 1, 2

Max. lift force

At lift points

1700 kg

(3750 lbs)

1750 kg (3860 lbs)

24 in. behind

lift points

1200 kg

(2650 lbs)

1250 kg (2760 lbs)

1350 kg (2980 lbs)

System pressure

17.7 MPa (180 kgf/cm

2

, 2560 psi)

PTO

Rear PTO

SAE 1-3/8, 6 splines

PTO/Engine speed

540 min

-1

(rpm) /

2426 min

-1

(rpm)

540 min

-1

(rpm) / 2476 min

-1

(rpm)

540 min

-1

(rpm) / 2403 min

-1

(rpm)

Mid-PTO (if equipped)

USA No.5 (KUBOTA 10-tooth) involute spline

PTO/Engine speed

2000 min

-1

(rpm)

/ 2451 min

-1

(rpm)

2000 min

-1

(rpm) / 2502 min

-1

(rpm)

2000 min

-1

(rpm) / 2429 min

-1

(rpm)

Model

L3560

L4060

L4760

L5460

L6060

4WD
