L3560, L4060, L4760, L5060, L5460, L6060, WSM

1-S68

(Continued)

NOTE

• Apply engine oil to the connecting rod screws and lightly

screw it in by hand, then tighten it to the specified torque.

9Y1210824ENS0058US0

Tightening torque

Connecting rod screw

40 to 45 N·m

4.1 to 4.5 kgf·m

30 to 33 lbf·ft

(6) Code Number

(7) Piston Ring Compressor

(A) Top Ring Gap
(B) Second Ring Gap
(C) Oil Ring Gap
(D) Piston Pin Hole

(a) 2.09 rad (120 °)

KiSC issued 03, 2016 A
