CLUTCH

L3560, L4060, L4760, L5060, L5460, L6060, WSM

2-S2

2. SERVICING SPECIFICATIONS

9Y1210824CLS0002US0

Item

Factory Specification

Allowable Limit

Clutch Pedal

Free travel

20 to 30 mm

0.78 to 1.18 in.

–

Clutch Disc Boss and Gear Shaft

(Manual Transmission and GST)

Backlash

(Displacement

Around Disc Edge)

–

2.0 mm

0.079 in.

Clutch Coupling Boss and Input Shaft

(HST)

Backlash

(Displacement

Around Clutch

Coupling)

–

1.5 to 2.0 mm

0.059 to 0.078 in.

Clutch Disc

Disc Surface to

Rivet Top (Depth)

–

0.3 mm

0.01 in.

Diaphragm Spring

Mutual Difference

–

0.5 mm

0.02 in.

Pressure Plate

Flatness

–

0.2 mm

0.008 in.

KiSC issued 03, 2016 A
