TRANSMISSION

L3560, L4060, L4760, L5060, L5460, L6060, WSM

3-M12

(Continued)

7. Because pressure in the GST clutch (27) is gradually pressurized by function of proportional reducing valve (26),

clutch is able to engage without shock and smoothly.

8. When the pressure in the circuit rises to the system pressure, pressure is kept. And the GST clutch is kept at

engaging condition until the next gear shifting.

State of energizing of solenoid
(Forward)

(Reverse)

9Y1210824TRM0016US0

N

1st

2nd

3rd

4th

5th

6th

7th

8th

9th

10th

11th

12th

Solenoid 1 (10)

ON

ON

ON

Solenoid 2 (16)

ON

ON

ON

Solenoid 3 (9)

ON

ON

ON

Solenoid 4 (14)

ON

ON

ON

Solenoid 5 (11)

ON

ON

ON

ON

Solenoid 6 (8)

(ON)

ON

ON

ON

ON

ON

ON

N

1st

2nd

3rd

4th

5th

6th

7th

8th

Solenoid 1 (10)

ON

ON

Solenoid 2 (16)

ON

ON

Solenoid 3 (9)

ON

ON

Solenoid 4 (14)

ON

ON

Solenoid 6 (8)

(ON)

ON

ON

ON

ON

No.

Solenoid

Color of wiring

(10)

Solenoid 1

Black

(16)

Solenoid 2

White

(9)

Solenoid 3

Red

(14)

Solenoid 4

Green

(11)

Solenoid 5, Sub-range Lo-Hi

Blue

(8)

Solenoid 6, Main range L-H

Yellow

KiSC issued 03, 2016 A
