TRANSMISSION

L3560, L4060, L4760, L5060, L5460, L6060, WSM

3-S9

9Y1210824TRS0173US0

Quick Engagement
While Starting or
Large shock While
Shifting

Oil level is too low

Check oil level or fill

oil to proper level

G-9

Transmission oil quality is too low

Fill correct fluid

G-9

GST valve improperly adjusted

Adjust GST valve

3-S22

Shift shock improperly adjusted

Adjust shift shock

3-S23

Temperature sensor damaged

Replace temperature

sensor

9-S50

Pressure switch damaged

Replace pressure

switch

9-S50

Symptom

Probable Cause

Solution

Reference

Page

KiSC issued 03, 2016 A
