2. SERVICING SPECIFICATIONS; Factory Specification; Allowable Limit- Page 332

TRANSMISSION

L3560, L4060, L4760, L5060, L5460, L6060, WSM

3-S13

2. SERVICING SPECIFICATIONS

ALL MODEL

Item

Factory Specification

Allowable Limit

Gear to Spline

Clearance

0.030 to 0.078 mm

0.0012 to 0.0030 in.

0.2 mm

0.008 in.

Shift Fork to Shifter Gear Groove

Clearance

0.20 to 0.40 mm

0.0079 to 0.015 in.

0.8 mm

0.03 in.

Gear to Shaft

Clearance

0.021 to 0.054 mm

0.00083 to 0.0021 in.

0.1 mm

0.004 in.

Shift Fork to Shifter Groove

Clearance

(Shuttle)

(Others)

0.20 to 0.45 mm

0.0079 to 0.017 in.

0.15 to 0.40 mm

0.0059 to 0.015 in.

0.8 mm

0.03 in.

0.8 mm

0.03 in.

Synchronizer Ring to Gear (In Contact)

Side Clearance

–

0.35 mm

0.014 in.

Spiral Bevel Gear

Turning Torque

4.0 to 6.3 N·m

0.40 to 0.65 kgf·m

2.9 to 4.7 lbf·ft

–

Spiral Bevel Gear to Spiral Bevel Pinion

Shaft

Backlash

0.15 to 0.30 mm

0.0059 to 0.012 in.

0.4 mm

0.02 in.

Differential Case Bore (Differential Case

Cover Bore) to Differential Side Gear Boss

• Differential Case Bore and Cover Bore

• Differential Side Gear Boss

Clearance

I.D.

O.D.

0.050 to 0.151 mm

0.0020 to 0.00594 in.

40.500 to 40.550 mm

1.5945 to 1.5964 in.

40.388 to 40.450 mm

1.5901 to 1.5925 in.

0.35 mm

0.014 in.

–

–

Differential Pinion Shaft to Differential

Pinion

• Differential Pinion Shaft

• Differential Pinion Shaft

Clearance

O.D.

I.D.

0.060 to 0.102 mm

0.0024 to 0.00401 in.

19.959 to 19.980 mm

0.78579 to 0.78661 in.

20.040 to 20.061 mm

0.78898 to 0.78980 in.

0.25 mm

0.0098 in.

–

–

Differential Pinion to Differential Side Gear

Backlash

0.15 to 0.30 mm

0.0059 to 0.011 in.

0.4 mm

0.02 in.
