ALL MODEL- Page 336
Kubota L3560 Owners Manual
Table of Contents
TRANSMISSION
L3560, L4060, L4760, L5060, L5460, L6060, WSM
3-S17
ALL MODEL
Item
N·m
kgf·m
lbf·ft
Joint bolt for main delivery pipe
118 to 137
12.0 to 14.0
86.8 to 101
Front loader pipe retaining nut
90.0 to 108
9.18 to 11.0
66.4 to 79.6
Joint bolt for PTO delivery pipe
35 to 39
3.5 to 4.0
26 to 28
Engine and clutch housing mounting screw
78 to 90
7.9 to 9.2
58 to 66
Engine and clutch housing mounting nut
103 to 117
10.5 to 12.0
76.0 to 86.7
Clutch housing and mid case mounting nut
103 to 117
10.5 to 12.0
76.0 to 86.7
Clutch housing and mid case mounting screw
78 to 90
7.9 to 9.2
58 to 66
Clutch housing bearing holder mounting screw
48 to 55
4.9 to 5.7
36 to 41
Stopper screw
35 to 44
3.5 to 4.5
26 to 32
Mid case and transmission case mounting screw
78 to 90
7.9 to 9.2
58 to 66
Mid case and transmission case mounting nut
103 to 117
10.5 to 12.0
76.0 to 86.7
PTO clutch valve mounting screw
23.5 to 27.4
2.40 to 2.74
17.4 to 20.2
Mid case bearing holder mounting screw
48 to 55
4.9 to 5.7
36 to 41
Rear wheel mounting screw and nut
220
22
160
Brake case mounting screw and nut
78 to 90
7.9 to 9.2
58 to 66
Lift arm pin mounting nut
78 to 90
7.9 to 9.2
58 to 66
Lift arm pin lock nut
63 to 72
6.4 to 7.4
47 to 53
Drawbar frame mounting screw (M12)
78 to 90
7.9 to 9.2
58 to 66
Drawbar frame mounting screw (M14)
167 to 196
17.0 to 20.0
123 to 144
Hydraulic cylinder hose retaining nut
35 to 48
3.5 to 4.9
26 to 35
Rear axle mounting screw and nut (M10 screw)
48 to 55
4.9 to 5.7
36 to 41
Rear axle mounting screw and nut (M10 nut (9T))
61 to 70
6.2 to 7.2
45 to 52
Rear axle mounting screw and nut (M12 screw)
78 to 90
7.9 to 9.2
58 to 66
Brake case mounting screw and nut
78 to 90
7.9 to 9.2
58 to 66
Lock nut (Spiral bevel pinion shaft)
150 to 190
15 to 20
110 to 140
Pinion bearing case mounting screw
40 to 44
4.0 to 4.5
29 to 32
Transmission bearing holder mounting screw
48 to 55
4.9 to 5.7
36 to 41
Lock nut (PTO shaft)
150 to 190
15 to 20
110 to 140
Bearing case mounting screw (PTO shaft)
24 to 27
2.4 to 2.8
18 to 20
Differential support mounting screw
48 to 55
4.9 to 5.7
36 to 41
Differential case cover mounting screw
48 to 55
4.9 to 5.7
36 to 41
Spiral bevel gear UBS screw
69 to 88
7.0 to 9.0
51 to 65
