TRANSMISSION

L3560, L4060, L4760, L5060, L5460, L6060, WSM

3-S18

MANUAL TRANSMISSION

GLIDE SHIFT TRANSMISSION

Item

N·m

kgf·m

lbf·ft

Release fork mounting screw

24 to 27

2.4 to 2.8

18 to 20

Main shift base mounting screw

24 to 27

2.4 to 2.8

18 to 20

Main shift arm mounting screw

9.81 to 11.2

1.00 to 1.15

7.24 to 8.31

Fulcrum screw

40 to 44

4.0 to 4.5

29 to 32

Item

N·m

kgf·m

lbf·ft

Release fork mounting screw

24 to 27

2.4 to 2.8

18 to 20

Shift pin mounting screw

13 to 14

1.3 to 1.5

9.4 to 10

GST valve mounting screw

43 to 48

4.3 to 4.9

32 to 35

Fulcrum screw

40 to 44

4.0 to 4.5

29 to 32

Shift pin mounting screw

13 to 14

1.3 to 1.5

9.4 to 10

GST valve mounting screw

43 to 48

4.3 to 4.9

32 to 35

Joint bolt for power steering delivery pipe and

regulating valve

40 to 49

4.0 to 5.0

29 to 36

Joint bolt for delivery pipe and hydraulic pump

40 to 49

4.0 to 5.0

29 to 36

Regulating valve mounting screw

18 to 20

1.8 to 2.1

13 to 15

Plate (Regulating valve)

9.8

1.0

7.2

Regulating valve case and support mounting screw

9.8

1.0

7.2

Joint bolt for GST delivery pipe to GST valve

35 to 39

3.5 to 4.0

26 to 28

Lower body mounting hex. socket head cap screw

9.8 to 10

1.0 to 1.1

7.3 to 7.9
