GENERAL

L3560, L4060, L4760, L5060, L5460, L6060, WSM

G-7

• Use sandpaper to remove rust from terminals.

• Repair deformed terminal. Make sure that there is no terminal

being exposed or displaced.

WSM000001GEG0075US0

• Make sure that there is no female connector being too open.

WSM000001GEG0076US0

• Make sure that plastic cover is large enough to cover whole

connector.

WSM000001GEG0077US0

[5] CIRCUIT TESTER

• Use tester correctly following manual provided with tester.

• Check for polarity and range.

WSM000001GEG0078US0

(1) Exposed Terminal

(2) Deformed Terminal

(3) Sandpaper

(4) Rust

(A) Correct

(B) Incorrect

(1) Cover

(A) Correct
(B) Incorrect
