[6] COLOR OF WIRING; Color of wiring- Page 37

GENERAL

L3560, L4060, L4760, L5060, L5460, L6060, WSM

G-8

[6]  COLOR OF WIRING

• Colors of wire are specified to the color codes.

• This symbol of "/" shows color with stripe (s).

(An example)

Red stripe on white color: W/R

WSM000001GEG0079US0

Color of wiring

Color code

Black

B

Brown

Br

Green

G

Gray

Gy or Gr

Blue

L

Light Green

Lg

Orange

Or

Pink

P

Purple

Pu or V

Red

R

Sky Blue

Sb

White

W

Yellow

Y

(1) Wire Color

(2) Stripe
