GENERAL

L3560, L4060, L4760, L5060, L5460, L6060, WSM

G-16

7. CHECK AND MAINTENANCE

 CAUTION

• Be sure to check and service the tractor on a flat place with engine shut off and pull the parking brake on

and chock the wheels.

9Y1210824GEG0008US0

[1] DAILY CHECK

To prevent trouble from occurring, it is important to know the condition of the tractor. Check the following items

before starting.

 CAUTION

To avoid personal injury:
Take the following precautions when checking the tractor.

• Park the machine on firm and level ground.
• Set the parking brake.
• Lower the implement to the ground.
• All residual pressure of the hydraulic system released.
• Stop the engine and remove the key.

9Y1210824GEG0009US0

Walk Around Inspection

Look around and under the tractor for such items as loose bolts,

trash build-up, oil or coolant leaks, broken or worn parts.

9Y1210824GEG0010US0

Checking and Refueling

 CAUTION

• Do not smoke while refueling.
• Be sure to stop the engine before refueling.

1. Turn the key switch to

"ON"

, check the amount of fuel by fuel

gauge.

2. Fill fuel tank when fuel gauge shows 1/4 or less fuel in tank.



Refueling alarm

Suppose that you try to refuel with the key switch at

"ON"

.

When you start refueling, the buzzer sounds intermittently.

When  the  tank  gets  close  to  full,  the  buzzer  starts  sounding

continuously. Stop refueling just when the buzzer sound turns from

intermittent to continuous.

IMPORTANT

• Do not permit dirt or trash to get into the fuel system.
• Be careful not to let the fuel tank become empty, otherwise

air will enter the fuel system, necessitating bleeding before
next engine start.

• Be careful not to spill during refueling. If should spill, wipe

it off at once, or it may cause a fire.

• To prevent condensation (water) accumulation in the fuel

tank, fill the tank before parking overnight.

9Y1210824GEG0011US0

Fuel tank capacity

51 L

13.5 U.S.gals

11.2 Imp.gals

(1) Fuel Tank Cap
