TRANSMISSION

L3560, L4060, L4760, L5060, L5460, L6060, WSM

3-S131

Thickness of Seal Ring

1. Measure the thickness of seal rings (1) with an outside

micrometer.

2. If the measurement is less than the allowable limit, replace it.

9Y1210824TRS0153US0

Thickness of seal ring

Factory specification

2.45 to 2.50 mm

0.0965 to 0.0984 in.

Allowable limit

2.0 mm

0.079 in.

(1) Seal Ring

KiSC issued 03, 2016 A
