REAR AXLE

L3560, L4060, L4760, L5060, L5460, L6060, WSM

4-S2

2. TIGHTENING TORQUES

Tightening torques of screws and nuts on the table below are especially specified.

(For general use screws and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.)

9Y1210824RAS0002US0

Item

N·m

kgf·m

lbf·ft

Rear wheel mounting screw and nut

197 to 225

20.0 to 23.0

145 to 166

ROPS lower frame mounting screw

167 to 196

17.0 to 20.0

123 to 144

Cabin mounting bolt and nut

124 to 147

12.6 to 15.0

91.5 to 108

Cabin mount bracket mounting screw (7T)

124 to 147

12.6 to 15.0

91.5 to 108

Cabin mount bracket mounting screw (9T)

167 to 196

17.0 to 20.0

123 to 144

Rear axle case mounting screw (M10)

48 to 55

4.9 to 5.7

36 to 41

Rear axle case mounting nut (M10, 9T)

61 to 70

6.2 to 7.2

45 to 52

Rear axle case mounting screw (M12)

78 to 90

7.9 to 9.2

58 to 66

Rear axle lock nut

197 to 245

20.0 to 25.0

145 to 180

KiSC issued 03, 2016 A
