BRAKES

L3560, L4060, L4760, L5060, L5460, L6060, WSM

5-S1

1. TROUBLESHOOTING

9Y1210824BRS0001US0

Symptom

Probable Cause

Solution

Reference

Page

Uneven Braking
Force

Brake pedal play unevenly adjusted

Adjust

5-S4

Brake disc worn

Replace

Cam plate warped

Replace

Brake Drags

Brake pedal play too small

Adjust

5-S4

Ball holes of cam plate for uneven wear

Replace

Brake pedal return spring weaken or broken

Replace

–

Brake cam rusted

Repair

5-S14

Poor Braking Force

Brake pedal play excessive

Adjust

5-S4

Brake disc worn

Replace

Cam plate warped

Replace
