L3560, L4060, L4760, L5060, L5460, L6060, WSM

5-S2

2. SERVICING SPECIFICATIONS

9Y1210824BRS0002US0

Item

Factory Specification

Allowable Limit

Brake Pedal

Free Travel

15 to 20 mm

0.59 to 0.78 in.

Cam Plate

Flatness

0.30 mm

0.012 in.

Cam Plate and Ball

Height

20.9 to 21.1 mm

0.823 to 0.830 in.

20.5 mm

0.807 in.

Brake Disc

Thickness

4.60 to 4.80 mm

0.181 to 0.188 in.

4.20 mm

0.165 in.

Plate

Thickness

2.54 to 2.66 mm

0.100 to 0.104 in.

2.1 mm

0.083 in.
