FRONT AXLE

L3560, L4060, L4760, L5060, L5460, L6060, WSM

6-S1

1. TROUBLESHOOTING

9Y1210824FAS0001US0

Symptom

Probable Cause

Solution

Reference

Page

Front Wheels Wander
to Right or Left

Tire pressure uneven

Adjust

G-73

Improper toe-in adjustment (improper alignment) Adjust

6-S5

Clearance between front axle case boss and

front axle bracket (front, rear) bushing excessive

Replace

6-S19

Front axle rocking force too small

Adjust

6-S6

Front wheel sway excessive

Replace

6-S5

Tie-rod end loose

Tighten

6-S9

Air sucked in power steering circuit

Bleed

7-S5

Front Wheels Can
Not Be Driven

Propeller shaft broken

Replace

6-S9

Front wheel drive gears in transmission broken

Replace

3-S75,

3-S94,

3-S119

Front differential gear broken

Replace

6-S14

Shift fork broken

Replace

Coupling displaced

Reassemble

6-S9

Noise

Gear backlash excessive

Adjust or replace

6-S15

Oil insufficient

Fill

G-9

Bearings damaged or broken

Replace

Gears damaged or broken

Replace

Spiral bevel pinion shaft turn force improper

Adjust

6-S17

KiSC issued 03, 2016 A
